NOCTUA CPU hűtő NH-U14S DX-4677 LGA4677, Barna Cooler Specification Socket
compatibility Intel Xeon LGA4677 Height (without fan) 165 mm Width (without fan)
150 mm Depth (without fan) 52 mm Weight (without fan) 797 g Height (with fan)
165 mm Width (with fan) 150 mm Depth (with fan) 111 mm Weight (with fan) 1136 g
Material Copper (base and heat-pipes), aluminium (cooling fins), soldered joints
& nickel plating NSPR 179 Max. TDP see NSPR Fan compatibility 140x150x25
(with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25
Scope of delivery 2x NF-A15 PWM premium fan NA-YC1 4-pin PWM y-cable NT-H1
high-grade thermal compound (pre-applied) SecuFirm2? mounting kit for LGA4677
NM-SMT5 TorxŽ T30 mounting tool Warranty 6 Years FAN Specification Model 2x
Noctua NF-A15 HS-PWM Bearing SSO2 Max. rotational speed (+/- 10%) 1500 RPM Min.
rotational speed @ 20% PWM (+/-20%) 300 RPM Max. airflow 140,2 m3/h Max.
acoustical noise 24,6 dB(A) Input power (max.) 1,56 W Voltage range 12 V MTTF >
150.000 h
