• 48 Khz, 64Bits Sample rate• 5 parametric EQ's each in-
and output• USB interface and user-friendly software included•
50 User PresetsDSP:Sample rate: 48 kHz, 64 bits NXP (Philips) DSP5-Bands Input
EQ:EQ Selections: Allpass, Bell, High Shelf, Low Shelf, NotchEQ Frequency
Selection: 20 to 20,000 Hz in 1 Hz steps on all EQ'sDelay:Output delay: Channel
independent from 0 to 8 mS 5-Bands Output EQ:EQ Selections: same as
inputType: Low Shelf 6, Low Shelf 12, High Shelf 6 and High Shelf
12Crossovers:Types: Linkwitz Riley, Bessel and Butterworth Slopes: 6, 12,
18, 24 dB/octaveCrossover frequencies: 20 to 20,000 in 1 Hz octave
stepsLimiter:Threshold points: -20 to +20 dBu in 0.5 dB stepsAttack time: Zero
Attack Time LimiterRelease times: 1 = shortest, 100 = endless long, in steps of
1.Miscellaneous:Memory Storage: 50 User presetsMute: All Output channels can be
individually muted Display: 2 x 16 dot matrix charactersLatency: 1.27 mSUSB
Interface: BackPower Supply: 6V DCPower Consumption: 4 WattPower Switch:
BackMeasurements: 483 x 155 x 44 mmAccessories: Power adapter, USB cable, DSP
software
